Semi Automatic Powder Filling and Sealing Machine
Precision Packing for Haldi, Masala, Atta, Chemicals, and Fine Powders
Overview
If you’re in the business of packaging fine, dusty, or dry powders like spices, flour, turmeric, protein powders, cosmetic powders, or chemicals, precision and consistency in filling are non-negotiable. Manual filling often leads to wastage, uneven weight, poor sealing, and hygiene concerns.
That’s where the Sonic Industries Semi-Automatic Powder Filling and Sealing Machine steps in. Designed for small to mid-scale industries, this compact yet powerful machine provides accurate dosing, fast operation, and professional-grade sealing—all while reducing labor dependency and material waste.
It’s the ideal solution for startups, spice mills, masala manufacturers, flour producers, or even chemical powder packers who want better productivity, consistent filling, and a neat pack appearance without investing in fully automated systems.
Technical Specifications Semi Automatic Powder Filling and Sealing Machine :
| Feature | Details |
|---|---|
| Machine Type | Semi-Automatic Powder Filling & Sealing Machine |
| Filling Range | 10g to 1kg (custom models available: 10g–50g, 50g–500g, etc.) |
| Filling System | Servo or Clutch-Brake Based Auger Filler |
| Sealing Mechanism | Horizontal Heat Sealer / Pneumatic Band Sealer |
| Pouch Type Supported | Center Seal, 3-Side Seal, Zipper Pouch, Stand-Up Pouch |
| Material Compatibility | PET, BOPP, Laminated Film, Foil, LDPE, Paper Laminates |
| Machine Construction | SS 304 Contact Parts / MS Powder-Coated Frame |
| Control Panel | Digital Controller with Counter / Speed Adjustment |
| Power Supply | 230V / Single Phase / 50Hz |
| Hopper Capacity | 15 – 25 Kg (depending on model) |
| Output Speed | 10–18 Packs Per Minute (depends on fill weight/operator) |
| Air Requirement | 6 CFM @ 6 Bar (only for pneumatic sealer variant) |
| Machine Dimensions | Approx. 1200 × 800 × 1800 mm |
| Net Weight | 150–200 Kg |
Key Features
High Accuracy Dosing
The auger-based filling system ensures ±1–2% fill accuracy, ideal for powders that clump, stick, or settle like haldi or protein powder.
Intelligent Filling System
-
Adjustable speed, delay, and fill time
-
Programmable fill memory (store multiple weights)
-
Sensor-based fill stop to avoid spillage
Reliable Heat Sealing
Choose from:
-
Band Sealer for continuous high-speed sealing
-
Impulse Sealer for low-cost heat sealing
-
Pneumatic Sealer for heavy-duty industrial applications
Hygienic Construction
SS 304 contact parts ensure safe contact with food-grade materials. Easy-to-open hopper for cleaning and refill.
Compact & Portable
Occupies minimal space, making it ideal for small factories, workshops, and packaging units.
Applications
| Industry | Use Case Examples |
|---|---|
| Spices & Masala | Turmeric, Red Chili Powder, Garam Masala, Coriander Powder |
| Ayurvedic & Herbs | Ashwagandha Powder, Amla Powder, Herbal Supplements |
| Bakery & Food | Baking Soda, Corn Flour, Cocoa Powder |
| Cosmetic | Talcum Powder, Face Powder, Body Dusting Powder |
| Pharmaceutical | ORS, Nutraceutical Powders, Calcium Supplements |
| Agrochemical | Pesticide Dust, Fertilizer Powder, Bio Enzymes |
| Industrial | Detergent Powder, Chemical Powders, Ceramic Powders |
Operating Workflow
-
Place the empty pouch under the auger nozzle
-
Pedal-operated or auto-filling trigger activates powder dispensing
-
Product fills into the pouch (controlled by auger system)
-
Move filled pouch to the sealing area
-
Sealing machine seals the pouch either horizontally or vertically
-
Collect and pack the sealed pouches into cartons
A single operator can handle the complete cycle efficiently.
Optional Add-ons
| Add-on | Benefit |
|---|---|
| Batch Coding Printer | Print MRP, MFG, EXP, Lot No. |
| Nitrogen Flushing Kit | For freshness in food, spices, and export packs |
| Vibrator Base | Helps settle powders and eliminate air pockets |
| Weighing Scale Interface | Cross-check pouch weight post filling |
| Stirrer Hopper Attachment | Ensures consistent flow of sticky powders like Haldi |
