Description
Designed for bulk filling with industrial precision, the Pneumatic Paste Filler – 300ml to 2600ml is a powerful and reliable semi-automatic solution for high-volume packaging operations. This heavy-duty filler is built to handle viscous, semi-viscous, and dense materials across multiple industries including food processing, pharmaceuticals, cosmetics, and chemicals.
With a massive filling range of 300ml to 2600ml, this model is ideal for filling large containers such as jars, tubs, pouches, bottles, and buckets. Built from SS304 stainless steel, it guarantees hygiene, corrosion resistance, and long service life, while the air-powered piston system ensures accurate, efficient, and clean filling — with no need for electricity.
Key Features
Large Filling Volume (300ml to 2600ml)
This machine allows precise adjustment for containers ranging from 300ml up to 2.6 litres — perfect for industries that deal in bulk packaging or institutional-sized products.
Pneumatic Drive – Air Powered
The machine runs entirely on compressed air, offering a safe, explosion-proof operation with no electricity involved. It is compatible with standard 1–2HP compressors.
High Accuracy (±1%)
The pneumatic piston-based filling system ensures consistent volume control, reducing waste and delivering standardized product weight every time.
SS304 Contact Parts
All material-contacting components are made of SS304 grade stainless steel for maximum hygiene, rust resistance, and food/pharma-grade compliance. SS316 option is available for corrosive or pharmaceutical applications.
Anti-Drip Nozzle
Equipped with a drip-free nozzle system to ensure clean fills without trailing or leakage — especially important when filling sticky or high-viscosity substances.
Manual Trigger via Foot Pedal
The semi-automatic machine is manually operated by the user through a foot pedal or optional hand button — giving complete control over timing and fill count.
Heavy Duty & Industrial Grade
Reinforced piston and nozzle assembly, thick steel frame, and large-capacity hopper make this machine suitable for continuous duty cycles in demanding environments.
Technical Specifications
- Filling Range: Pneumatic Paste Filler – 300ml to 2600ml
- Filling Accuracy: ±1%
- Operation Mode: Pneumatic (requires air compressor)
- Material: of Construction SS304 (Optional SS316)
- Air Pressure Required: 0.4 – 0.6 MPa
- Control Method: Foot Pedal / Push Button
- Nozzle Type: Stainless Steel Anti-drip Shut-off Nozzle
- Output Speed: 8 – 15 fills/min (based on product type)
- Hopper Capacity: 50 – 70 Litres (customizable)
- Machine Weight: 75 – 95 kg
- Mounting: Trolley or Stationary Bench Mount
